Try the award-winning all-in-one telematics solution and see for yourself!
The trial period allows you to use GPSauge in your own fleet with no obligation and experience the system’s benefits firsthand. This gives you the opportunity to put the performance of our comprehensive telematics solution to the test in various scenarios and familiarize yourself with how it works.
Request a trialThe Video System for Your Fleet
Four cameras, one hub—a complete view of the vehicle and its surroundings
The GPSauge Hub enhances your vehicle with a full-featured video system that combines live video, continuous recording, and remote access in a single compact unit. Up to four cameras can be connected directly to the hub—either analog or in AHD resolution up to 1080p. Setup takes just a few minutes using pre-assembled video and extension cables, and the 12- to 36-volt power supply from the vehicle’s electrical system works equally well for passenger cars, vans, and commercial vehicles.
As soon as the ignition is turned on, the hub begins operating. Via freely configurable trigger inputs—such as reverse gear, turn signals, or the hydraulic system—the corresponding camera image automatically appears on the driver’s display and disappears just as automatically. The trigger threshold can be set between 5 V and 16 V via a jumper and can thus be adapted to virtually any vehicle electrical system.
The HH421 model also records to an internal hard drive—for periods ranging from days to weeks, depending on resolution and storage capacity. Each recording includes a fixed overlay showing the date, time, camera position, and vehicle ID, making it uniquely identifiable in the event of damage. The driver can view recordings directly on the display and export relevant sequences as MP4 files.
Remote access is crucial for dispatch operations: Through the video portal, live footage can be viewed, and specific clips from a defined time in the vehicle can be requested—without interrupting operations. An RTSP stream is also available on-site via the Ethernet interface. Firmware, IP configuration, and on-screen overlays are conveniently managed via the service app on the driver’s display.
360° View
0%
Features
Up to 4 cameras
on a single hub—analog, AHD 720p, or 1080p; all positions can be freely assigned
Automatic Trigger View
The camera image automatically appears on the display when the vehicle is in reverse, the turn signal is activated, or the hydraulic system is in use
Selectable switching threshold
Selectable via jumper between 5 V and 16 V—compatible with virtually any vehicle electrical system
Continuous Recording (HH421)
Internal hard drive with loop recording—depending on the resolution, it can store days to weeks of video footage
Legally Valid Overlay
Date, time, time zone, camera position, and vehicle ID permanently displayed in the image
Playback on the Driver Display
Channel and date selection, 0.5x to 3x speed, skip function
Video on Demand from Headquarters
Targeted retrieval of clips by time and duration—without interrupting operations
Live video on the web portal
Access to all connected cameras directly from the dispatch center
MP4 Export
Save and share relevant sequences as a standard file
RTSP Stream over Ethernet
Local access using any standard media player, e.g., for the workshop and installation
Vehicle electrical system operation: 12–36 V
For passenger cars, vans, and commercial vehicles without an additional converter
Update via the Service App
Manage firmware, IP configuration, and on-screen displays directly on the driver's display
Status Indicator on the Device
LEDs indicate recording, connection, and hard drive status at a glance
The Professional Video System
The GPSauge HUB is THE camera system that was specifically developed for use in vehicles and is tailored in every detail to the needs of professional fleet operators.
The GPSauge HUB with a hard drive is designed for business users who want every trip to be fully documented.
The GPSauge HUB with a hard drive is designed for business users who want every trip to be fully documented.
Try it now with no obligation
Test the most professional telematics solution extensively, with no obligation and at no cost, and see for yourself why it’s the most powerful telematics system.
Simply provide your contact information, and your account manager will assist you from product selection to installation in your vehicle—he’ll take care of everything and be available to answer any questions you may have throughout the entire trial period.
- Free Trial
- based on your requirements
- tailored to your company’s structure
- Your personal account manager will guide you through the process
Awards
The performance, innovation, and flexibility of GPSoverIP telematics products have been consistently recognized through numerous awards.
This comprehensive telematics solution for a wide range of industries—comprising the integration of GPSauge (telematics hardware) and GPS-Explorer (the associated fleet management portal)—is the most award-winning and consistently reliable telematics system on the German market.
Data Exchange
Whether it’s statistics of all kinds, logbooks, or automatic tracking of working hours: With GPSoverIP, a vehicle’s movements can be transmitted seamlessly, reliably, and tamper-proof—like no other system can.
GPSoverIP is the patented technology specifically developed for the transmission of telematics data (https://en.wikipedia.org/wiki/GPSoverIP). The packet sizes to be transmitted are only about one-tenth those of conventional methods—while offering greater stability, higher density, and enhanced security.
Data Transmission Every Second
Since data transmission with GPSoverIP occurs every second, this is referred to as true live location tracking. This allows GPSoverIP to be used in motorsports, among other applications, as this field in particular relies on fast transmission without data loss.
In addition to the GPS position, the GPSoverIP method also transmits all types of telemetry data, which provides information on, among other things, operational status, door movement, or fuel level.
Compatibility Thanks to an Open Interface
Live visualization and access to historical data can be achieved in any software that interfaces with GPSoverIP’s open API. The API documentation, including validated interfaces, is available to all developers. This makes it incredibly easy to integrate the data generated by GPSoverIP into existing software solutions, such as inventory management systems.
A Wide Range of Communication Options
Using Bluetooth functionality specifically integrated for smart communication, you can easily pair the device with a smartphone or tablet. This pairing status gives you access to numerous additional features—such as order and route management or communication with the driver.
Together with the communication protocols and integrated technologies, this opens up unlimited opportunities for innovation in areas such as data exchange, data collection, application development, documentation, and much more.
You’ll be supported by numerous tools and applications that utilize these communication and data capture capabilities (container tracking, image and signature transmission, time tracking, etc.), all of which are included in the package. In addition, the GPSauge OBD offers detailed API documentation that allows you to connect your own smart application—if desired—to the telematics hardware for the exchange of any type of data (vehicle telemetry data, order status, digital tachograph data, etc.).
Quick and easy installation / setup
Installing the GPSaugen is incredibly simple, as the connections can be made in just a few minutes using automotive-certified connectors. This makes it possible to fully equip even a large fleet in a short amount of time.
For integration, you’ll receive a custom installation kit that can be used for any vehicle. It doesn’t matter whether the additional telemetry connection—if required—is made via a CAN bus (inductive), FMS bus, ISO bus, K-Line, MVB, J1708, OBD/OBD II, VDV300, etc. Depending on your requirements, you simply need to connect the power supply and the appropriate telemetry cable (e.g., CAN plug/OBD plug). The unit can be connected to either a 12-volt or a 24-volt vehicle power supply without an external voltage converter.
If desired, the telematics unit (GPSauge) is preconfigured and activated upon delivery, making it ready for use immediately after installation. Written documentation and video tutorials are available to assist with installation.
If you have any questions, please feel free to contact us at any time.
